7 to 42 (GP67)
8 is GND
Embedded Box PC 5000 IO Module PCIe expansion mapping
The PCIe slots on the expansion module on the top side of the Embedded Box PC are driven directly from the host PCIe bus. Since
it is generic PCIe expansion, there are no PCIe device-specic drivers integrated into the Windows 7 Professional SP1 OS image. If
there is specic PCIe card used on this slot, contact the vendor of that PCIe card to verify if they have Windows 7 Professional SP1
drivers.
Windows 7 Professional for Embedded Systems SP1
Overview
The Embedded Box PC is shipped with Windows 7 Professional for Embedded Systems. For more information, see https://
www.microsoft.com/windowsembedded/en-us/windows-embedded-enterprise-7.aspx.
Boot up and log in
Before conguring the Windows 7 Professional for Embedded Systems, connect a keyboard, mouse, and monitor to the Embedded
Box PC. Turn on the Embedded Box PC to boot into Windows.
1. Select regional settings.
2. Create a user account.
3. Read and agree to applicable End User Licence Agreements.
4. Select your preferred settings.
NOTE: Connect to a wireless network if available.
Windows 7 Professional for Embedded Systems basic functions
Watchdog Timer
The Watchdog Timer for Windows 7 Professional for Embedded Systems is controlled through a BIOS setting. Enter the BIOS during
boot by pressing F2. Select
System Conguration → Watchdog Timer Support → Enable Watchdog Timer in the BIOS setup
program.
The Watchdog Timer feature is used to recover the operating system during the following instances:
• During POST of the computer to ensure that the computer initialization is completed properly by the BIOS/UEFI.
• During the transition from BIOS/UEFI to the operating system through an operating system Watchdog Timer driver.
In both instances, without any human intervention, the Watchdog Timer reacts when the computer is not responding. The Watchdog
Timer is enabled and disabled under the BIOS setting Watchdog Timer.
TPM support
Windows 7 Professional for Embedded Systems supports TPM 1.2. For more information about TPM resources, see https://
technet.microsoft.com/en-us/library/cc749022(v=ws.10).aspx.
System shutdown
Click Start, and then click Shut down to shut down the Embedded Box PC.
System restart
Click Start, and click the arrow next to Shut down, and then click Restart to restart the Embedded Box PC.
LAN network conguration
1. Click Start and type Network in the search box.
2. Click Network and Sharing Center from the search result.
