3. From the left panel, click Change adapter settings.
4. Locate the required WWAN connection.
5. Right-click the WWAN connection, and then select Connect or Disconnect to connect to or disconnect from the WWAN
adapter, respectively.
Common port mappings on Embedded Box PC 5000 with Windows 7 Professional SP1
Serial port mapping
The following table shows the serial port mapping at the bottom of the Embedded Box PC 5000 with the Dell factory installed
Windows 7 Professional SP1 OS image.
Table 1. Serial port mapping
Number Port type Connector Device node
1 RS232/422/485 DB9 COM1
2 RS232/422/485 DB9 COM2
3 RS232/422/485 DB9 COM3
4 RS232/422/485 DB9 COM4
Embedded Box PC 5000 GPIO module In/Out mapping
The GPIOs ports on the Embedded Box PC and Nuvoton NCT6793D uses index/data pair of CPU I/O addresses 2Eh/2Fh to access
NCT6793D.
GPIO 8 Out pin# to NCT6793D pin# map:
0 to 121 (GP00)
1 to 122 (GP01)
2 to 123 (GP02)
3 to 2 (GP03)
4 to 3 (GP04)
5 to 4 (GP05)
6 to 5 (GP06)
7 to 6 (GP07)
8 is GND
GPIO 8 In pin# to NCT6793D pin# map:
0 to 50 (GP60)
1 to 49 (GP61)
2 to 48 (GP62)
3 to 47 (GP63)
4 to 45 (GP64)
5 to 44 (GP65)
6 to 43 (GP66)
23
