10. After the restore operation is complete, click Finish to restart the computer.
Windows 7 Professional SP1 basic functions
BIOS update
BIOS updates for the Embedded Box PC may be downloaded from dell.com/support. The download includes an executable that may
be ran from the local machine.
Watchdog Timer
The Watchdog Timer for Windows 7 Professional SP1 is controlled through a BIOS setting. Enter the BIOS during boot by pressing
F2. Select
System Conguration → Watchdog Timer Support → Enable Watchdog Timer in the BIOS setup program.
The Watchdog Timer feature is used to recover the operating system during the following instances:
• During POST of the computer to ensure that the computer initialization is completed properly by the BIOS/UEFI.
• During the transition from BIOS/UEFI to the operating system through an operating system Watchdog Timer driver.
In both instances, without any human intervention, the Watchdog Timer reacts when the computer is not responding. The Watchdog
Timer is enabled and disabled under the BIOS setting Watchdog Timer.
TPM support
Windows 7 Professional SP1 supports TPM 1.2. For more information about TPM resources, see https://technet.microsoft.com/en-
us/library/cc749022(v=ws.10).aspx.
System shutdown
Click Start, and then click Shut down to shut down the Embedded Box PC.
System restart
Click Start, and click the arrow next to Shut down, and then click Restart to restart the Embedded Box PC.
LAN network conguration
1. Click Start and type Network in the search box.
2. Click Network and Sharing Center from the search result.
The Network and Sharing Center window appears.
3. From the left panel, click Change adapter settings.
WLAN network conguration
1. Click Start and type Network in the search box.
2. Click Network and Sharing Center from the search result.
The Network and Sharing Center window appears.
3. From the left panel, click Change adapter settings.
Bluetooth conguration
1. Click Start and type Bluetooth in the search box.
2. Click Change Bluetooth settings from the search result.
The Bluetooth Settings dialog box appears.
DW5580 network conguration
Follow the Service Manual to install and congure the DW5580 module and the corresponding carrier SIM card for the system.
Once the module and the SIM card are installed, follow these steps to connect and disconnect from WWAN.
1. Click Start and type Network in the search box.
2. Click Network and Sharing Center from the search result.
The Network and Sharing Center window appears.
