Conguring WLAN network
Click the Start icon then the settings icon. Click Devices and the Bluetooth to congure the wireless devices on the Embedded Box
PC.
Conguring WWAN (DW5580) network
NOTE: For instruction on installing the WWAN card and SIM card, see the Service manual for your system at
www.dell.com/support. After installing the WWAN module and SIM card:
1. Click the Start icon then the settings icon.
2. Click Network & Internet.
3. Locate the WWAN connection in the Wi-Fi section and connect (or disconnect) the WWAN module.
Common port mappings
Serial port mapping
The table lists the serial port mapping on the Embedded Box PC 5000 and the multifunction port cable, with the Dell factory
installed Windows 10 Pro OS.
Table 4. Serial port mapping
Serial port number Port type Connector Device Node
1 RS232/422/485 DB9 COM1
2 RS232/422/485 DB9 COM2
3 RS232/422/485 DB9 COM3
4 RS232/422/485 DB9 COM4
Embedded Box PC 5000 GPIO In/Out mapping
The GPIOs ports on the Embedded Box PC and Nuvoton NCT6793D uses index/data pair of processor I/O Addresses 2Eh/2Fh to
access NCT6793D.
GPIO 8 Out pin# to NCT6793D pin# map:
0 to 121 (GP00)
1 to 122 (GP01)
2 to 123 (GP02)
3 to 2 (GP03)
4 to 3 (GP04)
5 to 4 (GP05)
6 to 5 (GP06)
7 to 6 (GP07)
8 is GND
GPIO 8 In pin# to NCT6793D pin# map:
0 to 50 (GP60)
1 to 49 (GP61)
2 to 48 (GP62)
