Ports and connectors
Audio/video
• One HDMI port
• One VGA port
• Two DisplayPort
• One line-in port
• One line-out port
• One microphone port
NOTE: For more information about the display options,
see Display Options.
Network
• Two RJ45 ports
• Two wireless ports
• Two mobile broadband antenna ports
I/O port
• One CANbus port (optional)
• Four RS232/RS422/RS485 ports
• GPIO 16-bit
USB
• Four USB 3.0 ports
• Four USB 2.0 ports
Communications
WiFi Dual-band 802.11b/g/n/ac
Bluetooth Bluetooth 4.1 LE
Power requirements
Phoenix connector input voltage/current 12 VDC/10.80 A-26 VDC/5 A
Power input voltage/current 12 VDC/10.80 A-26 VDC/5 A
WARNING: Connect a certied SELV power to either Phoenix connector or the Barrel connector only. The connection
of two power sources may damage equipment and present risk of re.
RTC coin-cell battery (lithium ion)
Type CR-2032H BR-2032 Others
Manufacturer
• Hitachi Ltd.
• Maxell Ltd.
Panasonic Corp. Varies depending on the battery
type
Maximum abnormal charging rate:
Voltage 3 V 3 V 3 V
Current 10 mA 10 mA 10 mA
Standard UL1642 UL1642 UL1642
Approval UL (MH12568) UL (MH12210) UL (MHxxxxx)
Environmental requirements
Temperature range:
Operating: Hard drive 0°C to 40°C (32°F to 104°F)
38
