228 Installing Blade Components

Figure 3-40. Installing and Removing the Heat Sink (PowerEdge M905)

1 heat sink

NOTE: You must install the heat

sink in the orientation shown here.

2 screws (4)

3 socket CPU2 4 socket CPU4

5 socket CPU3 6 socket CPU1
