232
Installing Blade Components
Figure 3-44.
Installing and Removing a Heat Sink (PowerEdge M610)
1
socket CPU2
2
heat sink
NOTE:
Y
ou must install the heat
sink in the orientation
shown here.
3
screws (4)
4
socket CPU1
2
1
3
4
231
233
