238
Installing Blade Components
Figure 3-50.
Installing and Removing an AM
D Processor (PowerEdge
M905, M805, or
M605)
1
pin-1 corner of socket
2
pin-1 corner of processor
3
processor
4
socket-release lever
5
processor shield
6
notch in processor
3
5
6
1
2
4
237
239
