Quad-Port Mezzanine Cards
Table 1-15 illustrates the I/O module port mapping for full-height blades with
quad-port mezzanine cards.
NOTE: For a detailed mapping of each PowerEdge system, see the document
Quadport Capable Hardware for the M1000e Modular Chassis on
support.dell.com/manuals.
Table 1-15. I/O Module Port Assignments—Full-Height Blades (not applicable to
M610x)
Blade
n and Blade ( n + 8) I/O Module
NOTE: n denotes a variable
value from 1 to 8.
B1 C1 C2 B2
Mezz_FAB_B_Blade n_Port1 Port n
Mezz_FAB_B_Blade n_Port2 Port n
Mezz_FAB_B_Blade n_Port3 Port
(n+16)
Mezz_FAB_B_Blade n_Port4 Port
(n+16)
Mezz_FAB_C_Blade n_Port1 Port n
Mezz_FAB_C_Blade n_Port2 Port n
Mezz_FAB_C_Blade n_Port3 Port
(n+16)
Mezz_FAB_C_Blade n_Port4 Port
(n+16)
Mezz_FAB_B_Blade
n+8_Port1
Port
(n+8)
Mezz_FAB_B_Blade
n+8_Port2
Port
(n+8)
Mezz_FAB_B_Blade
n+8_Port3
Port
(n+24)
Mezz_FAB_B_Blade
n+8_Port4
Port
(n+24)
Mezz_FAB_C_Blade
n+8_Port1
Port
(n+8)
