Dell Alienware Aurora R8 - Screw List

Screw list
NOTE: Screw color may vary with the conguration ordered.
Component Secured to Screw type Quantity Screw image
3.5-inch hard-drive cage Chassis #6-32 X 1/4'' 2
2.5-inch hard-drive cage Chassis #6-32 X 1/4'' 4
Power-supply unit hinge Chassis #6-32 X 1/4'' 6
#6-32 X 1/4'' BLK 3
Power-supply unit Power-supply unit
hinge
#6-32 X 1/4'' 4
Power-supply unit bracket #6-32 X 1/4'' 2
Optical-drive assembly Chassis #6-32 X 1/4'' 2
System board Chassis #6-32 X 1/4'' 8
Top cover Chassis #6-32 X 1/4'' 2
Top I/O assembly Chassis #6-32 X 1/4'' BLK 4
Processor-cooling assembly bracket Chassis #6-32 X 1/4'' BLK 2
Processor-cooling assembly radiator Processor-cooling
assembly bracket
#6-32 X 1/4'' BLK 4
Top-chassis fan assembly Chassis #6-32 X 1/4'' 1
Top-chassis fan bracket Chassis #6-32 X 1/4'' BLK 1
Antenna assembly Chassis #6-32 X 1/4'' 2
15
