Removing the processor-cooling assembly
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the left-side cover.
2 Remove the right-side cover.
3 Remove the top cover.
Procedure
1 Remove the four screws (#6-32 X 1/4") that secure the radiator and fan assembly to the radiator and fan cage.
2 Follow the procedure from step 1 to step 4 in "Removing the power-supply unit".
3 Loosen the two captive screws that secure the VR heat sink to the system board.
53
