12 | About your display
6 USB 3.1 upstream
ports (3)
Connect the USB cable that comes with your display
to the computer. Once this cable is connected, you
can use the USB downstream connectors on the
display and the touch screen function on the display.
NOTE: Refer to section on “Input sources and USB
pairing”.
7 USB 3.1 downstream
ports (3)
Connect your USB device.
You can only use this connector after you have
connected the USB cable to the computer and USB
upstream connector on the display.
8 USB charging port USB 3.1 downstream port with BC 1.2 charging
capability at 2A(Maximum).
9 RJ-45 connector Remote Network Management and control of display
via RJ-45.
Input sources and USB pairing
Input sources USB upstream
HDMI 1 USB 1
HDMI 2 USB 2
HDMI 3
USB 3
DP
Bottom view
Label Description
1, 2 Speakers
3 Power on/off button
