Coin-cell battery
Removing the coin-cell
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Disconnect the battery cable.
5. Remove the IO board.
NOTE: The Coin-cell is installed on the IO board.
About this task
Steps
1. Use a plastic scribe to pry up the coin-cell battery from the slot on the IO daughter board.
2. Remove the coin-cell battery from the IO daughter board.
40
Disassembly and reassembly
