Removing the system board - Cirrus Logic audio
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the battery.
5. Remove the WLAN.
6. Remove the SSD.
7. Remove the hard drive assembly.
8. Remove the memory
9. Remove the system fan.
10. Remove the heatsink.
NOTE: The system board can be removed along with the heat sink.
11. Remove the display assembly.
About this task
74 Disassembly and reassembly
