22 ā”‚ About Your Dell Canvas 27
USB 3.0 Type-A downstream port
Pin number Signal name
1 VBUS
2 D-
3 D+
4 GND
5 StdA_SSRX-
6 StdA_SSRX+
7 GND_DRAIN
8 StdA_SSTX-
9 StdA_SSTX+
Shell Shield
