Setting Up the Dell Canvas 27 │ 31
VESA wall mounting (Optional)
NOTE: Use M4 x 8 mm screws to connect the monitor to the wall-mounting kit. Wall
mount Dell Canvas 27 using VESA-compatible wall mount kit (75 x 75 mm / 100 x 100mm
/ 200 x 200 mm). Refer to the instructions that come with the VESA-compatible wall
mounting kit.
1. Place the Dell Canvas 27 on a soft cloth or cushion on a stable, flat table.
2. Attaching the VESA (optional purchase):
a, Place the VESA mount on the back of Dell Canvas 27.
Use a Phillips crosshead screwdriver to tighten the screws.
b, Follow the direction of the arrow and push the VESA cover until it snaps into place.
c, Use a Phillips crosshead screwdriver to tighten the screws.
3. Attach the mounting bracket from the wall mounting kit to the Dell Canvas 27.
4. Mount the Dell Canvas 27 on the wall by following the instructions that comes with
the wall mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket with minimum
weight/load bearing capacity of 9.5 kg (20.94 lb).
