Dell Canvas 27 User Manual

About Your Dell Canvas 27 │ 21
USB 3.0 Type-C Connector (1 x downstream and 1 x upstream)
Pin Signal Assignment Pin Signal Assignment
A1 GND B12 GND
A2 TX1+ B11 RX1+
A3 TX1- B10 RX1-
A4 VBUS B9 VBUS
A5 CC B8 SBU2
A6 D + B7 D -
A7 D - B6 D +
A8 SBU1 B5 VCONN
A9 VBUS B4 VBUS
A10 RX2- B3 TX2-
A11 RX2+ B2 TX2+
A12 GND B1 GND
