22 Basic Operation
www.dell.com | support.dell.com
Figure 3-1. Main Dialog Box
NOTE: You can also press the <ctrl> key twice within one second to launch the OSCAR interface. You
can use this key sequence in any place you see
<Print Screen> throughout this installer/user’s guide.
Viewing the Status of Your Switch
The status of the servers in your system is indicated in the right columns of the
Main
dialog box.
The following table describes the status symbols.
Table 3-1. OSCAR Interface Status Symbols
Symbol Description
Server Interface Pod (SIP) is online (green circle).
SIP is offline or is not operating properly.
Connected switch is online.
Connected switch is offline or is not operating properly.
SIP is being upgraded (yellow circle).
