26 Basic Operation
www.dell.com | support.dell.com
To access the Setup dialog box:
1 Press <Print Screen> to launch the OSCAR interface. The Main dialog box appears.
2 Click Setup . The Setup dialog box displays.
Figure 3-2. Setup Dialog Box
Assigning Server Names
Use the Names dialog box to identify individual servers by name rather than by port number. The
Names list is always sorted by port order. Names are stored in the SIP, so even if you move the
cable/server to another ARI port, the name and configuration will be recognized by the appliance.
NOTE: If a server is turned off, the SIP will not appear in the Names list.
To access the Names dialog box:
1 Press <Print Screen> to launch OSCAR. The Main dialog box appears.
2 Click Setup - Names. The Names dialog box appears.
Scan Set up a custom scan pattern for up to 16 servers.
Security Set passwords to restrict server access.
Enable the screen saver.
Devices Identify the appropriate number of ports on an attached
legacy switch.
Names Identify servers by unique names.
Switch Choose the switch mode and the share mode time-out.
Table 3-3. Setup Features to Manage Routine Tasks for Your Servers (continued)
Feature Purpose
