Dell Console Switch User Manual

34 Basic Operation
www.dell.com | support.dell.com
2 Select Enable Screen Saver .
3 Type the number of minutes for Inactivity Time (from 1 to 99) to delay activation of the
screen saver.
4 Choose Energy if your monitor is E NERGY S TAR
®
compliant; otherwise select Screen .
CAUTION: Monitor damage can result from the use of Energy mode with monitors not compliant with
E
NERGY STAR®.
5
(Optional) Click Test to activate the screen saver test, which lasts 10 seconds then returns you
to the
Security dialog box.
6 Click OK .
NOTE: Activation of the screen saver mode disconnects the user from a server; no server is selected.
The status flag displays Free.
To exit the screen saver mode:
Press any key or move your mouse. The
Main dialog box appears and any previous server
connection will be restored.
To turn off the screen saver:
1 In the Security dialog box, clear Enable Screen Saver .
2 Click OK .
To immediately turn on the screen saver:
Press
<Print Screen> , then press <Pause> .
Displaying Version Information
The OSCAR interface enables you to display the versions of the Console Switch and the SIP
firmware. For optimum performance, keep your firmware current. For more information, see
"Appendix A: Flash Upgrades".
To display version information:
1 Press <Print Screen> . The Main dialog box appears.
2 Click Commands - Display Versions. The Version dialog box appears. The top half of the box
lists the subsystem versions in the appliance.

Dell Console Switch Specifications

General

Brand	Dell
Model	Console Switch
Category	Switch
Language	English
