Page #41 background imageLoading...
Page #41 background image
Identifier GUID-CA1E9EB7-809B-4CE5-97EC-688EB320D087
Version 2
Status Released
General options
Table 20. General
Option Description
System Information Displays the following information:
System Information: Displays BIOS Version, Service Tag, Asset Tag, Ownership Tag,
Ownership Date, Manufacture Date, and the Express Service Code.
Memory Information: Displays Memory Installed, Memory Available, Memory Speed,
Memory Channel Mode, Memory Technology, DIMM A Size, DIMM B Size, DIMM C
Size, DIMM D Size.
PCI Information: Displays Slot1, Slot2, Slot3.
Processor Information: Displays Processor Type, Core Count, Processor ID, Current
Clock Speed, Minimum Clock Speed, Maximum Clock Speed, Processor L2 Cache,
Processor L3 Cache, HT Capable, and 64-Bit Technology.
Device Information: Displays SATA-0, SATA 1, SATA 2, SATA 3, M.2 PCIe SSD-0,
M.2 PCIe SSD-1, LOM MAC address, LOM2 MAC address, Video Controller, Audio
Controller.
Boot Sequence Allows you to specify the order in which the computer attempts to find an operating system
from the devices specified in this list.
Advanced Boot Options Allows you to select the Enable Legacy Option ROMs option, when in UEFI boot mode. By
default, this option is selected.
Enable Legacy Option ROMs
Enable Attempt Legacy Boot
Default None Selected
UEFI Boot Path Security This option controls if the system will prompt the user to enter the Admin password when
booting a UEFI boot path from the F12 Boot Menu.
Always, Except Internal HDDDefault
Always
Never
Date/Time Allows you to set the date and time settings. Changes to the system date and time take
effect immediately.
.
Identifier
GUID-99C12568-5110-445F-AA11-52BB3012467E
Version 2
Status Released
System information
Table 21. System Configuration
Option Description
Integrated NIC Allows you to control the onboard LAN controller. The option Enable UEFI Network Stack is
not selected by default. The options are:
Disabled
Enabled
Enabled w/PXE (default)
Integrated NIC2 Allows you to control the onboard LAN controller. The option Enable UEFI Network Stack is
not selected by default. The options are:
Disabled
System setup 41
