Table 5. System Configuration(continued)
Option Description
NOTE: SATA is configured to support RAID mode.
Drives
7820 Tower Allows you to enable or disable various drives on board.
The options are:
• MiniSAS PCIe SSD-0
• SATA-0
• SATA–2
• SATA–4
• ODD–0
• MiniSAS PCIe SSD-1
• SATA–1
• SATA–3
• SATA–5
• ODD–1
All the options are set by default.
PCIe Drives
Allows the enabling of Front PCIe attached Ports.
• MiniSAS PCIe SSD-0
• MiniSAS PCIe SSD-1
• MiniSAS PCIe SSD-2
• MiniSAS PCIe SSD-3
All the options are set by default.
SMART Reporting
This field controls if the hard drive errors for the integrated drives
are reported during system startup. This technology is part of the
SMART(Self-Monitoring Analysis and Reporting Technology)
specification.
• Enable SMART Reporting
This option is not set by default.
USB Configuration
Allows you to enable or disable the internal USB configuration.
The options are:
• Enable USB Boot Support
• Enable Front USB Ports
• Enable Internal USB Ports
• Enable USB 3.0 Controller
• Enable Rear USB Ports
All the options are set by default.
Front USB Configuration
Allows you to enable/disable Front USB ports.
The options are:
• USB3 Type A *
• USB Type C port 2 (Right) *
• USB Type C port 1 (Right) *
All the options are set by default.
Rear USB Configuration
Allows you to enable/disable Rear USB ports.
The options are:
104 System Setup
