Installing the slim ODD
1. Slide the slim ODD into the slot on the chassis.
2. Tighten the screw to secure the slim ODD to the chassis.
3. Install the side cover.
4. Follow the procedure in After working inside your computer.
Front input and output bezel
Removing front input and output bezel
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. side cover
b. front bezel
3. To remove the front input and output(I/O) bezel:
a. Pry the four retention tabs[1] from the chassis and push the bezel out from the chassis[2].
Removing and installing components
35
