96 Removing and Installing Parts
NOTICE: Do not route card cables over or behind the cards. Cables routed over the cards can prevent the
computer cover from closing properly or cause damage to the equipment.
NOTICE: To connect a network cable, first plug the cable into the network device and then plug the cable into the
computer.
13
Replace the computer cover, reconnect the computer and devices to electrical outlets, and then turn
them on.
14
If you installed a sound card:
a
Enter system setup, select
Integrated Audio Controller
, and then change the setting to
Off
.
b
Connect external audio devices to the sound card’s connectors. Do not connect external audio
devices to the integrated microphone, speaker/headphone, or line-in connectors on the back panel.
15
If you installed an add-in network adapter and want to disable the integrated network adapter:
a
Enter system setup, select
Integrated NIC Controller,
and then change the setting to
Off
.
b
Connect the network cable to the add-in network adapter’s connectors. Do not connect the
network cable to the integrated connector on the back panel.
16
Install any drivers required for the card as described in the card documentation.
1 release tab 2 card retention mechanism 3 card retention door
3
1
2
