Removing and Installing Parts 97
Removing a PCI Express Card
1
Follow the procedures in "Before You Begin" on page 77.
2
Remove the computer cover (see "Removing the Computer Cover" on page 78).
3
If present on your computer, rotate the lever on the chassis wall upward.
1 card retention door 2 release tabs (2) 3 lever on chassis wall (may not
be present on all computers)
4 filler bracket 5 alignment guide 6 alignment bar
1
2
4
5
6
3
