Dell E1909W - Attachment 2- Schematic

Service Manual
44
10
631102090762R
D
LCP 19" M190PW01-V0B(AUO)RoHS
0
PC A
20
701000008600R
chassis-for-cmo-assy,LE19E6
MMP,
1
PC A
30
501110100110R
Dell-logo-KW265,LE19E6
DEMETER,
1
PC A
40
505040208700R
chassis-mylar,LE19E6
久威,富准,
1
PC A
50
505040208710R
panel-mylar,LE19E6
久威,富准,
1
PC A
60
509000001000R
BOLT,#4-40x12.5,Ni ROHS
高億,
4
PC A
70
509016304200R
SCREW,I,CROSS,M3*4,Zn-CcROHS
高億,
4
PC A
80
509016306200R
SCREW,I,CROSS,M3*6,Zn-Cc
高億,
2
PC A
90
509146306202R
SCREW,P,CROSS,W/WAS,M3*6,Zn-Cc
立侑,高億,
5
PC A
100
509446309100R
SCREW B CROSS W/W-SPK M3*9 Zn ROHS
高億,鴻益進,
1
PC A
110
430303001680R
HRN LVDS FFC 30P 160mm
P-TWO,
1
PC A
120
430300801920R
HRN ASSY 2x4P to8P 345mm UL1571#28 V1909
FOXCONN,HEIGHTEN,JVE,
1
PC A
130
791711300800R
PCBA,I/F BOARD W/O SPK,LE19E6-812 ROHS
1
PC
140
791711400800R
PCBA,P/I BOARD W/O SPK,LE19E6-812 ROHS
1
PC
150
791711500000R
PCBA,KEYPAD BOARD,LE19E6 ROHS
1
PC
160
506381000800R
TAPE,ACE,85x45mm,LE1913
1
PC A
Attachment 2- Schematic
1.Interface board schematic
