not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
1. Follow the safety guidelines listed in the Safety instructions section.
2. Follow the procedure listed in the Before working inside your system section.
Procedure
1. Locate the USB port or USB memory key on the system board.
To locate the USB port, see the System board connectors section.
2. If installed, remove the USB memory key from the USB port.
Figure 48 Removing the internal USB memory key
a. USB memory key
b. USB port
3. Insert the replacement USB memory key into the USB port.
Figure 49
Installing the internal USB memory key
a. USB memory key
b. USB port
After you finish
1. Follow the procedure listed in the After working inside your system section.
2. While booting, press F2 to enter System Setup and verify that the system detects the USB
memory key.
Installing and removing system components
126 Dell PowerEdge R430 Owner's Manual
