Inside the system
CAUTION Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
Figure 21 Inside the system—with a cabled power supply
1. control panel
2. cable routing latch
3. power supply unit
4. expansion-card riser connector (2)
5. memory-module socket (B3, B4)
6. processor 2
7. memory-module socket (B1, B2)
Installing and removing system components
Dell PowerEdge R430 Owner's Manual 89
