Table 62. System board jumpers and connectors
Item Connector Description
1. P_RG1_CP Right panel connector
2. J_WS_PWRBTN Power button connector
3. J_INTRUSION_DET1 Intrusion switch connector
4. J_FAN1U_2 Cooling fan connector
5. Processor 2 Processor socket 2
6. J_BATT_SIG Battery signal connector
7. J_BATT_PWR Battery power connector
8. CP Left control panel connector
9. B6, B12, B5, B11, B4, B10, B7, B1, B8, B2, B9, B3 Memory module sockets
10. J_ODD Optical drive connector
11 J_BP_SIG1 Backplane signal connector 1
12 J_BP1 Backplane connector 1
13 J_BP2 Backplane connector 2
14 J_STORAGE_M4 SAS connector 4
15 J_STORAGE_M3 SAS connector 3
16 J_STORAGE_M2 SAS connector 2
17 J_STORAGE_M1 SAS connector 1
18 J_SATA_C SATA connector
19 J_USB_INT Internal USB port
20 J_IDSDM_vFLASH IDSDM/vFlash module connector
21 J_RISER2 Riser 2 connector
22 J_NDC Network Daughter Card connector
23 J1 SATA connector
24 J_SATA_B SATA connector
25 J_SATA_A SATA connector
26 J_BP_SIG0 Backplane signal connector 0
27 J_BPO Backplane power connector
28 J_R1_SS82_2 Riser 1 connector
29 J_TPM_MODULE1 TPM module connector
30 BATTERY Battery connector
31 NVRAM_CLR Clear NVRAM
32 PWRD_EN Reset BIOS password
33 LED's System board diagnostic LED indicators
34 J_VGA VGA connector
35 J_STORAGE1 Mini PERC controller connector
36 J_USB_INT1 USB connector
37 Processor 1 Processor socket 1
170 Jumpers and connectors
