For more information, see the Online Help.
5. Click Apply to save your settings.
Conguring IP Range Attributes Using RACADM
You can congure the following IP Range attributes for CMC using RACADM:
• IP range checking feature
• Range of IP addresses that you want to block from accessing CMC
• IP Range Mask that you want to block from accessing CMC
IP ltering compares the IP address of an incoming login to the IP address range that is specied. A login from the incoming IP
address is allowed only if both the following are identical:
• cfgRacTuneIpRangeMask bit-wise and with incoming IP address
• cfgRacTuneIpRangeMask bit-wise and with cfgRacTuneIpRangeAddr
• To enable the IP range checking feature, use the following property under cfgRacTuning group:
cfgRacTuneIpRangeEnable <0/1>
• To specify the range of IP addresses that you want to block from accessing CMC, use the following property under
cfgRacTuning group:
cfgRacTuneIpRangeAddr
•
To specify the IP Range Mask that you want to block from accessing CMC, use the following property under cfgRacTuning
group:
cfgRacTuneIpRangeMask
Conguring Virtual LAN Tag Properties for CMC
Virtual LANfunctionality enables multiple VLANs to coexist on the same physical network cable and to segregate the network trac
for security or load management purposes. When you enable the VLAN functionality, each network packet is assigned a VLAN tag.
Conguring Virtual LAN Tag Properties for CMC Using RACADM
1. Enable the Virtual LAN (VLAN) capabilities of the external chassis management network:
racadm config -g cfgLanNetworking -o
cfgNicVLanEnable 1
2. Specify the VLAN ID for the external chassis management network:
racadm config -g cfgLanNetworking -o cfgNicVlanID <VLAN id>
The valid values for <VLAN id> are 1– 4000 and 4021– 4094. Default value is 1.
For example:
racadm config -g cfgLanNetworking -o cfgNicVlanID
1
3. Then, specify the VLAN priority for the external chassis management network:
racadm config -g cfgLanNetworking -o
cfgNicVLanPriority <VLAN priority>
The valid values for <VLAN priority> are 0–7. Default value is 0.
For example:
racadm config -g cfgLanNetworking -o
cfgNicVLanPriority 7
You can also specify both the VLAN ID and the VLAN priority with a single command:
racadm setniccfg -v <VLAN id> <VLAN priority>
For example:
racadm setniccfg -v 1 7
