Figure 6. POST Lower DRAM Memory test screen
9. When the cursor moves into the upper-left corner, press the Delete key until the Press <DEL> string displays in the
console window.
Figure 7. Setup screen
NOTE:
If you do not press the Delete key fast enough, the boot up screen displays. If this occurs, you must power the
VEP1405 unit off and power it on again to restart the boot up process.
Create a serial console connection 11
