3. Insert front faceplate tabs into the slots in the system and press until the front faceplate locks into place.
Figure 100. Installing the front faceplate
4. Tilt at an angle and align the system side cover with the slots in the system, then slide the cover towards the front of the
system until locks into place.
5. Using a Phillips 2 screwdriver, tighten the screws that secure the system side cover to the chassis.
110
Installing and removing system components
