Front view of the system
Figure 1. Front view of 8 x 3.5-inch drive system
Table 1. Features available on the front of the system
Item Ports, panels, and slots Icon Description
1 BOSS S2 module
(optional)
N/A This slot supports BOSS S2 module.
2 Power button Indicates if the system is powered on or off. Press the power button to
manually power on or off the system.
NOTE: Press the power button to gracefully shut down an ACPI-
compliant operating system.
3 Information tag N/A The Information tag is a slide-out label panel that contains system
information such as Service Tag, NIC, MAC address, and so on. If you have
opted for the secure default access to iDRAC, the Information tag will also
contain the iDRAC secure default password.
4 System health and ID
indicator
Indicates the system health. For more information, see the System health and
system ID indicator codes section.
PowerEdge T350 system overview 9
