3. Replace eight screws (M2.5x4) that secure the display-assembly hinges to the palm-rest and keyboard assembly.
4. Turn the display assembly over.
5. Connect the display cable to the connector on the system board and close the latch to secure the cable.
6. Adhere the tape that secures the display cable to the system board.
7. Route the antenna cables through the routing guides on the fan and adhere the tape that secures the antenna cables to the
system board .
Next steps
1. Install the wireless card.
2. Install the rear cover
3. Install the base cover.
4. Follow the procedure in After working inside your computer.
Removing the display assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the rear cover.
4. Remove the wireless card.
About this task
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
