Dell Inspiron N7110 User Manual

Palm-Rest Assembly 31
8
Palm-Rest Assembly
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information,
see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
CAUTION: Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
CAUTION: To help prevent damage to the system board, remove the main battery
(see "Removing the Battery" on page 15) before working inside the computer.
Removing the Palm-Rest Assembly
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove the battery (see "Removing the Battery" on page 15).
3 Follow the instructions from step 3 to step 4 in "Removing the Optical
Drive" on page 17.
4 Remove the 11 screws that secure the palm-rest assembly to the computer
base.
5 Remove the keyboard (see "Removing the Keyboard" on page 27).
book.book Page 31 Friday, April 13, 2012 2:02 PM

Dell Inspiron N7110 Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Home Premium
Optical Drive	DVD+/-RW
Networking	10/100 Ethernet
Card Reader	8-in-1 Media Card Reader
Webcam	1.0 MP integrated webcam
Processor	Intel Core i3/i5/i7
Display	17.3-inch HD+ (1600x900)
Storage	Up to 1TB HDD
Graphics	Intel HD Graphics 3000 / NVIDIA GeForce GT 525M
Battery	6-cell
Chipset	Intel HM67 Express
Audio	Stereo speakers
Ports	USB 2.0, USB 3.0, HDMI, VGA, RJ-45
Wireless	Wi-Fi 802.11b/g/n
