54 Speaker Assembly
Replacing the Subwoofer
1
Follow the procedures in "Before You Begin" on page 9.
2
Place the subwoofer on the computer base.
3
Connect the subwoofer cable to the connector on the system board.
4
Replace the palm-rest assembly (see "Replacing the Palm-Rest Assembly"
on page 35).
5
Replace the keyboard (see "Replacing the Keyboard" on page 29).
1 subwoofer cable 2 subwoofer
