Dell Laser Printer 2230d - Page 12

1 Front door release button
2
Paper stop
3 Standard exit bin
4
Printer control panel
5
System board door
6
Standard 250-sheet tray (Tray 1)
7
Optional 250-sheet drawer (Tray 2)
8 Manual feeder door
9
Front door
The following illustration shows the printer configured with an optional 550-sheet drawer:
Learning about the printer
12
