 Power Button Assembly
Dell™Latitude™D430

1. Follow the instructions in "BeforeYouBegin"onpage7.

2. Remove any installed PC Cards from the PC Card slot.

3. Remove any installed memory modules or Mini PCI cards (see Memory and Mini-Cards).

4. Remove the hard drive (see Hard Drive).

5. Remove the hinge cover (see Hinge Cover).

6. Remove the keyboard (see Keyboard).

7. Remove the internal card with Bluetooth®wireless technology (see Internal Card With Bluetooth®Wireless Technology).

8. Remove the display assembly (see Display Assembly).

9. Remove the palm rest (see Palm Rest).

10. Disconnect the power-button assembly connector from the system board.

11. Push the assembly toward the inside of the computer base and lift out.
Back to Contents Page

CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
CAUTION: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.
NOTICE: Handle components and cards by their edges, and avoid touching pins and contacts.
1
power button assembly
2
computer base
