Page #10 background imageLoading...
Page #10 background image
GPS
supported by Mobile Broadband full mini card
PortsandConnectors
Audio
one combo microphone/headphone connector
Video
15-pin VGA connector
Network adapter
RJ-45 connector
USB, eSATA
l one USB 2.0 compliant connector
l one USB 2.0/eSATA connector
Smart-card reader
integrated smart-card reader
Mini card support (internal expansion slots)
l one dedicated half mini card slot for WLAN
l one dedicated full mini card slot for WWAN
l one half mini card slot for UWB
ExpressCards
NOTE: The ExpressCard slot is designed only for ExpressCards. It does NOT support PC Cards.
Cards supported
34 mm ExpressCards
Contactless Smart Card (optional)
Supported Smart Cards/Technologies
ISO14443A 106 kbps, 212 kbps,
424 kbps, and 848 kbps
ISO14443B 106 kbps, 212 kbps,
424 kbps, and 848 kbps
ISO15693
HID iClass
FIPS201
NXP Desfire
Fingerprint Reader (Optional)
Type
swipe
Display
Type
13.3 inch HD white light-emitting diode (WLED)
Active area (X/Y)
HD 293.42 mm x 164.97 mm (11.55 inches x 6.50
inches)
Dimensions:
Height
183.6 mm (7.23 inches)
Width
308.1 mm (12.13 inches)
Diagonal
337.82 mm (13.3 inches)
Maximum resolution
1366 x 768 at 262 K colors
Maximum brightness
220 nits
Operating angle
0 degrees (closed) to 135 degrees
Refresh rate
60 Hz
Viewing angles
Horizontal
40 degrees / 40 degrees
Vertical
15 degrees / 30 degrees
Pixel pitch
0.2148 mm
Keyboard
Number of keys
l United States and Canada: 83 keys
l Europe: 84 keys
l Japan: 87 keys
Layout
QWERTY/AZERTY/Kanji
Size
full sized (19.05 mm key pitch)
Touchpad
Active area
X-axis
70.00 mm (2.76 inches)
Y-axis
37.00 mm (1.46 inches)
Resolution
600 dpi
Battery
