Dell Latitude E4310 - Removing the Hinge Covers; Replacing the Hinge Covers

Back to Contents Page
Hinge Covers
Dell Latitude E4310 Service Manual
Removing the Hinge Covers
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the screw that secures the hinge covers to the computer.
4. Slide the hinge cover toward the back of the computer and remove the hinge cover.
5. Repeat step 3 and step 4 to remove the other hinge cover.
Replacing the Hinge Covers
To replace the hinge covers, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe Flash Player from Adobe.com in order to view the illustrations below.
