Dell Latitude E4310 User Manual

Back to Contents Page
System Setup
Dell Latitude E4310 Service Manual
Entering System Setup
Boot Menu
Navigation Keystrokes
System Setup Menu Options

Your computer offers the following BIOS and System Setup options:
l Access System Setup by pressing <F2>
l Bring up a one-time boot menu by pressing <F12>
l Access the Intel AMT settings by pressing <Ctrl> + <P>
Entering System Setup
Press <F2> to enter System Setup and make changes to user-definable settings. If you have trouble entering System Setup using this key, press <F2> when
the keyboard lights first flash.
Boot Menu
Press <F12> when the Dell logo appears to initiate a one-time boot menu with a list of the valid boot devices for the computer. Diagnostics and Enter Setup
options are also included in this menu. The devices listed on the boot menu depend on the bootable devices installed in the computer. This menu is useful
when you are attempting to boot to a particular device or to bring up the diagnostics for the computer. Using the boot menu does not make any changes to
the boot order stored in the BIOS.
Navigation Keystrokes
Use the following keystrokes to navigate System Setup screens.
System Setup Menu Options
The following tables describe the menu options for the System Setup program.
Navigation
Action
Keystroke(s)
Expand and collapse field
<Enter>
Exit BIOS
<Esc> or click Exit
Apply settings
click Apply
Reset defaults
click Load Defaults
General
Option
Description
System Information
Lists the primary hardware features of your computer. There are no configurable options in this section.
l System Information
l Memory Information
l Processor Information
l Device Information
Battery Information
Displays the status of the battery and the type of AC adapter connected to the computer.
Boot Sequence
Specifies the order in which the computer attempts to find an operating system.
l Diskette drive
l Internal HDD (IRRT)
l USB Storage Device
l CD/DVD/CD-RW Drive
l Onboard NIC
l Cardbus NIC
To change the order in which the computer attempts to find an operating system, select the device to be changed in
the list then click the up/down arrows or use the keyboard <PgUp> or <PgDn> keys to change the boot order of the
device.
Clear the check boxes to remove a device from the list of bootable devices.
Date/Time
Displays current date and time settings.
NOTE: System Configuration contains options and settings related to integrated system devices. Depending on your computer and installed devices,
the items listed in this section may or may not appear.
System Configuration

Dell Latitude E4310 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-520M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QS57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	2 x 2 GB
Discrete graphics card model	-
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
AC adapter power	65 W
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cable lock slot type	Kensington
Product color	Black
Sustainability certificates	ENERGY STAR
Pointing device	Touchpad
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	215 mm
Width	323 mm
Weight	1540 g
Height (rear)	30.6 mm
Height (front)	26.5 mm
