Dell Latitude E4310 User Manual

Option
Description
Integrated NIC
Allows you to configure the integrated network controller. The options are: Disabled, Enabled, and Enabled w/PXE
Default Setting: Enabled w/PXE
Parallel Port
Allows you to configure the parallel port on the docking station. The options are: Disabled, AT, PS2, and ECP
Default Setting: AT
Serial Port
Allows you to configure the integrated serial port. The options are: Disabled, COM1, COM2, COM3, and COM4
Default Setting: COM1
SATA Operation
Allows you to configure the internal SATA hard-drive controller. The options are: Disabled, ATA, AHCI, and RAID On
Default Setting: RAID On
NOTE: SATA is configured to support RAID mode.
Miscellaneous Devices
Allows you to enable or disable the following devices:
l External USB Port
l Microphone
l eSATA Ports
l Media Card
l Internal Modem
l Fixed Bay
l ExpressCard
l Hard Drive Free Fall Protection
l Camera and Microphone
Default setting: All are enabled.
Latitude ON Reader
Allows you to configure the operating mode of the Latitude ON Reader.
Default Setting: Enable Latitude ON reader
Keyboard Illumination
Allows you to configure the keyboard illumination feature. The options are: Disabled, Auto ALS and Input, and Auto
Input Only
Video
Option
Description
Ambient Light Sensor
Allows you to configure the Ambient Light Sensor.
Default Setting: Disabled
LCD Brightness
Allowsyoutosetthedisplaybrightnessdependinguponthepowersource(On Battery and On AC).
Security
Option
Description
Admin Password
Allows you to set, change, or delete the administrator (admin) password.
NOTE: You must set the admin password before you set the system or hard drive password.
NOTE: Successful password changes take effect immediately.
NOTE:Deletingtheadminpasswordautomaticallydeletesthesystempasswordaswell.
Default Setting: Not Set
System Password
Allows you to set, change, or delete the system password. When set, your computer requests you to enter the system
password every time your computer turns on or restarts.
Default Setting: Not Set
Internal HDD Password
Allows you set, change, or delete the password on the system's internal hard disk drive (HDD). Successful changes
take place immediately and require a system restart. The HDD password travels with the hard drive, so the HDD is
protected even when installed in another system.
Password Bypass
Allows you to bypass the system and internal hard drive password prompts when your computer restarts or resumes
from standby.
You can set Password Bypass to: Disabled and Reboot Bypass.
NOTE: You cannot bypass the system or hard drive password when you turn on your computer that has been
turned off.
Default Setting: Disabled
Password Change
Allows you to enable of disable changes to the system and hard drive passwords when the admin password is set.
Default Setting: Allow Non-Admin Password Changes checked
Strong Password
Allows you to enable of disable the option to enforce strong passwords.
If enabled, all passwords set on the computer must contain at least one uppercase character, one lowercase character
and be at least 8 characters long.
Enabling this feature automatically changes the default minimum password length to 8 characters.
Default Setting: Disabled
TPM Security
Allows you to enable or disable the Trusted Platform Module (TPM) on the computer.
NOTE: Disabling this option does not change any settings you may have made to the TPM, or delete any information or
keys you may have stored there.
When TPM is enabled, the following options are available:

Dell Latitude E4310 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-520M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QS57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	2 x 2 GB
Discrete graphics card model	-
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
AC adapter power	65 W
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cable lock slot type	Kensington
Product color	Black
Sustainability certificates	ENERGY STAR
Pointing device	Touchpad
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	215 mm
Width	323 mm
Weight	1540 g
Height (rear)	30.6 mm
Height (front)	26.5 mm
