Dell Latitude E4310 User Manual

l Deactivate—Disables the TPM. The TPM restricts access to the stored owner information and does not execute
any commands that use TPM resources.
l Activate—Enables and activates the TPM.
l Clear—Clears the owner information stored in the TPM.
Default Setting: Disabled
Computrace®
Allows you to enable or disable the optional Computrace software. The options are Deactivate, Disable, and Activate.
NOTE: The Activate and Disable options will permanently activate or disable the feature and no further changes will
be allowed.
Default Setting: Deactivate
CPU XD Support
Allows you to enable or disable the Execute Disable mode of the processor.
Default setting: Enabled
Non-Admin Setup Changes
Allows you to determine whether changes to the system setup options are allowed when an Administrator password is
set. If disabled, the system setup options are locked by the admin password.
Default Setting: Disabled
Password Configuration
AllowsyoutodeterminetheminimumandmaximumlengthofAdministratorandSystempasswords.
Admin Setup Lockout
Allows you to prevent users from entering system setup when an Administrator password is set.
Performance
Option
Description
Multi Core Support
Enables or disables multi-core support for the processor. Options are: All, 1, and 2
Default Setting: All
Intel®SpeedStep™
Enables or disables the Intel SpeedStep feature.
Default Setting: Enabled
Intel®TurboBoost™
Enables or disables the Intel TurboBoost performance.
Default Setting: Enabled
Power Management
Option
Description
AC Behavior
Allows you to enable or disable the computer from turning on automatically when an AC adapter is connected.
Default Setting: Wake on AC Disabled
Auto On Time
Allows you to set the time at which the computer must turn on automatically.
You can set the number of days, if any, when you would like the system to turn on automatically. The settings are
Disabled, Everyday, or Weekdays.
Default setting: Disabled
USB Wake Support
Allows you to enable or disable the ability of USB devices to wake the computer from Standby.
This feature is only functional when the AC power adapter is connected. If the AC power adapter is removed when the
computer is in Standby mode, the system setup will remove power from all of the USB ports to conserve battery
power.
Default Setting: Disabled
Wake on LAN/WLAN
Allows the computer to turn on by a special LAN signal or from Hibernate mode when triggered by a special wireless
LAN signal. Wake-up from the Standby mode is unaffected by this setting and must be enabled in the operating
system.
l Disabled — Do not allow the system to power on when it receives a wake-up signal from the LAN or wireless
LAN.
l LAN Only — Allow the system to be powered on by special LAN signals.
l WLAN Only — Allow the system to be powered on by special WLAN signals.
l LAN or WLAN — Allow the system to be powered on by special LAN or wireless LAN signals.
Default Setting: Disabled
ExpressCharge
Allows you to enable or disable the ExpressCharge feature.
NOTE: ExpressCharge may not be available for all batteries.
Default Setting: ExpressCharge
Charger Behavior
Allows you to enable or disable the battery charger.
If disabled, the battery will not charge or lose power when the computer is connected to an AC adapter.
Default setting: Enabled
POST Behavior
Option
Description
Adapter Warnings
Allows you to enable or disable the BIOS warning messages when you use certain power adapters. The BIOS displays
these messages if you attempt to use a power adapter that has too little capacity for your configuration.
The factory default setting is Enabled.

Dell Latitude E4310 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-520M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QS57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	2 x 2 GB
Discrete graphics card model	-
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
AC adapter power	65 W
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cable lock slot type	Kensington
Product color	Black
Sustainability certificates	ENERGY STAR
Pointing device	Touchpad
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	215 mm
Width	323 mm
Weight	1540 g
Height (rear)	30.6 mm
Height (front)	26.5 mm
