Dell M1710 - Page 140

140 Specifications
Interfaces:
Internal HDA bus
External microphone-in connector, stereo
headphones/speakers connector
Speaker two stereo 4-ohm main speakers and one
subwoofer with bass reflex port
Internal speaker amplifier 2-W per channel main amplifier and 5-W
Class D subwoofer amplifier
Volume controls keyboard shortcuts, program menus, media
control buttons
Audio controller Sigmatel STAC92XX codec
Display
Type (active-matrix TFT) WUXGA
Dimensions:
Height 245.0 mm (9.64 inches)
Width 383.0 mm (15 inches)
Diagonal 431.8 mm (17 inches)
Maximum resolution 1920 x 1200 at 16.7 million colors
Refresh rate 60 Hz
Operating angle 0° (closed) to 180°
Viewing angle (typical):
Horizontal ±60°
Vertical ±45°
Pixel pitch 0.191 mm (17-inch display)
Power consumption (
panel with
backlight) (typical):
7.54 W
Controls brightness can be controlled through
keyboard shortcuts
Keyboard
Number of keys 87 (U.S. and Canada); 88 (Europe);
91 (Japan)
Layout QWERTY/AZERTY/Kanji
Audio (continued)
