Specifications 141
Touch Pad
X/Y position resolution
(graphics table mode) 240 cpi
Size:
Width
73.0-mm (2.88-inch) sensor-active area
Height
42.9-mm (1.69-inch) rectangle
Battery
Type 9-cell "smart" lithium ion
Dimensions:
Depth
88.5 mm (3.48 inches)
Height
21.5 mm (0.83 inch)
Width
139.0 mm (5.47 inches)
Weight 0.40 kg (0.88 lb) (9 cell)
Voltage 10.8 VDC
Charge time (approximate)
:
Computer off
2 hours (at 100% in 2 hours)
1 hour (at 80% in 1 hour)
Operating time Battery operating time varies depending on
operating conditions and can be significantly
reduced under certain power-intensive
conditions. See "Power Problems" on
page 105.
See "Using a Battery" on page 43 for more
information on battery life.
Life span (approximate) 300 discharge/charge cycles
Temperature range:
Operating
0° to 35°C (32° to 95°F)
Storage
–40° to 65°C (–40° to 149°F)
