126 Adding and Replacing Parts
Mini-Card
If you ordered a Mini-Card with your computer, the card is already installed.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product
Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as a connector on the back of the computer).
NOTICE: To avoid damaging the system board, you must remove the battery before you begin working inside the
computer.
1
Follow the procedures in "Before You Begin" on page 117.
2
Turn the computer over and loosen the captive screws from the Mini-Card/modem cover.
3
Place your finger under the cover at the indentation, and lift the cover to remove it.
4
If a Mini-Card is not already installed, go to step 5. If you are replacing a Mini-Card, remove the
existing card:
a
Disconnect the antenna cables from the Mini-Card.
