38 | Setting Up the Monitor
Removing the Cable Cover
1 Gently pull and stretch out the edge of the cable over.
2 Remove th
e three tabs on the upper part of the cable cover from the groove on the
back of the monitor.
Wall Mounting (Optional)
(Screw dimension: M4 x 10 mm).
Refer to the instructions that come with the VESA-compatible wall mounting kit.
1 Place the mon
itor panel on a soft cloth or cushion on a stable, flat table.
2 Remove the stand.
3 Use a
Phillips crosshead screwdriver to remove the four screws securing the plastic
cover.
4 Attach the mounting bracket from the wall mounting kit to the monitor.
5 Mount
the monitor on the wall by following the instructions that comes with the
wall mounting kit.
NOTE: For use on
ly with UL-listed wall mount bracket with minimum weight/load
bearing capacity of 5.0 kg.
