Dell Networking N4032 Reference Guide

4 Expansion Modules for Dell Networking Switches
Table of contents
Revisions ............................................................................................................................................................................................. 3
Executive Summary .......................................................................................................................................................................... 5
1 Introduction ................................................................................................................................................................................ 6
2 SFP+ Modules and Optic Requirements ................................................................................................................................ 7
3 Blade Switches and Corresponding Modules ....................................................................................................................... 8
3.1 Dell PowerEdge M1000e Blade Chassis ..................................................................................................................... 8
3.1.1 Dell Networking M8024-k ............................................................................................................................................. 9
3.1.2 Dell Networking M8024 ............................................................................................................................................... 10
3.1.3 Dell Networking M6220 ................................................................................................................................................ 11
3.1.4 Dell Networking MXL .................................................................................................................................................... 12
3.1.5 Dell Networking M6348 ............................................................................................................................................... 12
4 Rack Switches and Corresponding Modules ...................................................................................................................... 13
4.1 Dell Networking N3000 Series (N3024, N3024F, N3024P, N3048, N3048P) ................................................... 13
4.2 Dell Networking N4000 Series (N4032, N4032F,N4064, N4064P) .................................................................... 14
4.3 Dell Networking 8100 Series (8132, 8132F, 8164, and 8164F) .............................................................................. 15
4.4 Dell Networking 7000 Series (7024, 7024P, 7024F, 7048, 7048P, 7048R, and 7048R-RA) ........................... 16
4.5 Dell Networking 62xx Series (6224, 6224P, 6224F, 6248, 6248P) ....................................................................... 17

Dell Networking N4032 Specifications

General

Rack Units	1U
Layer	Layer 3
Manageable	Yes
Stackable	Yes
MAC Address Table Size	32, 000 entries
Jumbo Frame Support	Yes
Jumbo Frame Size	9216 bytes
Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C (32°F to 113°F)
Uplink Ports	8 x 10 Gigabit Ethernet 10GBASE-T
Power Supply	Dual, hot-swappable
Operating Humidity	10% to 90% non-condensing
