Dell OptiPlex 3070 Small Form Factor User Manual

2. Follow the procedure in After working inside your computer
Expansion card
Removing expansion card
1. Follow the procedure in Before working inside your computer.
2. Remove the Side cover.
3. To remove the expansion card:
a) Pull the metal tab to open the expansion card latch [1].
b) Pull the release tab at the base of the expansion card [2].
NOTE:
Applies to x16 card slot, x1 card has no release tab.
c) Disconnect and lift the expansion card away from the connector on the system board [3].
Removing and installing components
19

Dell OptiPlex 3070 Small Form Factor Specifications

General

Brand	Dell
Model	OptiPlex 3070 Small Form Factor
Category	Desktop
Language	English
