3. Install the:
a) Expansion cards
b) Side cover
4. Follow the procedure in After working inside your computer.
Hard drive assembly
Removing the hard drive assembly
1. Follow the procedure in Before working inside your computer.
2. Remove the Side cover.
3. To remove the hard drive:
a) Disconnect the hard drive data cable and power cable from the connectors on the hard drive [1, 2].
b) Push the release tab and lift the hard drive assembly from the system [3].
Removing and installing components
23
